HLY

HLY26655000‐BT

26650 HLY 5000 mAh high drain BUTTON TOP lithium-ion battery

These 26650 lithium rechargeable batteries are mainly used for high powered flashlights/torches and can be used for many other high drain applications such as DIY battery packs, electric scooters, e bikes, solar power packs etc.

Please note these batteries come with built in PROTECTION board and are much safer than the Non-PROTECTION version.

Your device must be able to facilitate a Li-Ion 26650 lithium battery - do not purchase if your device does not fit DIAMETER 26mm x LENGTH 70mm size batteries, if unsure check user manual or contact supplier.

Device application:

  • High power flashlight / torch
  • Electric scooters
  • Electric bikes / e-bikes
  • Solar power packs
  • Portable lights
  • Power banks
  • EV (Electric Vehicles)
  • DIY projects
  • And much more !

Specifications:

  • Manufacturer: HLY
  • Model: ICR26650
  • Size: 26500
  • Rechargeable: YES
  • Nominal Capacity: 5000 mAh
  • Nominal Voltage: 3.6V
  • Discharge End Voltage: 2.5V
  • Standard Charging Current: 1.25A
  • Charging maximum Voltage: 4.20V
  • Continuous Discharging Current: 15A
  • Peak discharge rating: 30A
  • Positive cap: Button top
  • Protection: PROTECTED
  • Dimensions:  x 26 mm (D) x 70 mm (Length including protection board)
  • Weight: 99g
  • Operational Temperature Range: 0 to 50 degrees C (best below 30 degrees C)



Note: Batteries will only have test charge. Ensure batteries are fully charged to reach full capacity. Failure to do so may lead to long term cell issues.



Usage & Charging

!!!!! IMPORTANT!!!!! These are immensely powerful batteries, and extreme care should be taken using them. Only use with brand name, quality chargers (like LiitoKala, Nitecore, XTAR) and equipment! Unfortunately, we cannot replace batteries that are damaged by non-compliant chargers or equipment. There are so many chargers on the market, we cannot possibly keep track of which ones will work with these batteries. You will have to contact the charger manufacturer to ensure it can charge these batteries without damaging them. Please ensure you only use these (or any other Lithium Ion) batteries with proper Lithium-Ion chargers and equipment. Lithium-Ion batteries can easily be damaged by charging them with too high current or exceeding the maximum rated current discharge. In worst case Lithium-Ion batteries can explode or catch fire when used improperly!

Use at your own risk. We do NOT accept any responsibly for damage, injury or death caused by improper use of these batteries!

  • Do not overcharge! Ensure the charger voltage does not exceed the batteries stated full charge voltage.
  • Do not over-discharge! Ensure the equipment you use do not draw more current than the batteries “Maximum Continuous Discharge Current”.
  • Do not leave batteries discharged for a long period! Leaving Li-Ion batteries in a discharged state can incur irreversible damage – creating a loss in capacity and a loss in cycles.
  • Do not short circuit your batteries! NEVER short circuit a 18650 (or more other) batteries! Short circuiting can cause a huge surge of current that will potentially burn out your battery, damage your equipment, and even cause serious injury to you!
  • Do not let your batteries touch each other or other metallic items! Keeping your batteries loose, such as in your pockets, is a serious way to have your batteries fail and seriously harm you. There are battery holders and covers to keep your batteries safe.
  • Do not dispose any battery in a fire! There are dangerous chemicals in batteries. If you try to burn your batteries, they will release dangerous fumes and will probably explode. Always dispose your old batteries to a battery recycling centre.
